three phase hybrid solar inverter IMEON 9.12

IMEON 9.12

IMEON 9.12 is dedicated to three-phase photovoltaic systems for self-production with storage. This solar hybrid inverter with a power of 9kW perfectly suits with residential, collective dwellings and small scale tertiary, industrial. It works in all configurations: Smart-Grid / Off-Grid / Back-Up / On Grid.

Photovoltaic power from 4 to 12 kWp

Storage capacity from 5 to 100 kWh

Integrated WiFi and Web server.

Lithium-Ion batteries compatibility.

Warranty up to 20 years

A.I. INSIDE

Buying an IMEON is a way to anticipate the future. With an embedded artificial intelligence,
IMEON will evolve with the tools of tomorrow. No more obsolescence!

Thanks to its Artificial Intelligence implanted in the heart of a 32-bit Texas Instruments ARM Cortex processor with 8 GB of storage, IMEON has unmatched capabilities!

The integrated WiFi means local or remote control of the IMEON through overhauled monitoring interface.

IMEON has the ability to integrate new technical developments and regulatory changes thanks to its new architecture and specialized applications.

A flexible architecture to allow a wide range of storage capacities ranging from 2KWh to 15KWh per IMEON.

Self-consumption, back-up, isolated site, grid connected site, Virtual Power Plant…IMEON is the solution ready to function in all scenarios.

IMEON instantly secures the power supply of your essential devices (lighting, WiFi, freezer, water heater…).

ACCESSORIES FOR IMEON 9.12

Imeon 3.6 is associated with a range of accessories and a reliable and secure connection to simplify the installation. Robust and practical, these accessories contribute to the high quality of our inverters

Download your favourite apps!

Imeon Energy is constantly developing applications to help you get the most of your energy manager’s capabilities.

Some applications will be particularly appreciated for residential installations in order to optimize the initial investment. These applications will allow your IMEON to integrate the latest technologies.

With IMEON, you will be astonished and impressed by the possibilities of your inverter!

LED Smart Lighting-1 (1)
Imeon app grid export control
Imeon app weather coupling
Imeon app forecast consumption
Imeon app multistacking
imeon application mailalert
imeon application peak shaving
imeon application seasonal cutoff
Voice connect
UPnP-Server
imeon application charging controller
imeon_application_lithium_battery_manager
imeon application imeon community

TECHNICAL SPECIFICATIONS

GRID AC (ON-GRID & OFF-GRID)

  • Rated output power

    9000 W

  • Maximum output power (3 sec)

    12000 W

  • AC voltage / Frequency (input & output)

    3/N/PE; 230/400 Vac (±15 %) / 50 Hz, 60 Hz (±5 Hz)

  • Nominal output current

    13 A / phase

  • Maximum input current

    17,5 A / phase

  • Feed in to grid

    Programmable (yes by default)

  • Energy consumption priorities

    Programmable (PV / Storage / Grid)

SOLAR INSTALLATION

  • Maximum input power

    Up to 12 000 Wp (1)

  • Number of MPPT inputs

    2

  • MPPT voltage range

    380 V – 750 V

  • Maximum input current

    2 x 18 A

  • Maximum input voltage

    850 V

  • Maximum efficiency

    DC to AC : >95,5% (94,5% EU)

BATTERY & CHARGE

  • DC nominal voltage

    48 Vdc

  • Maximum discharge current

    200 A

  • Maximum charging current

    160 A

  • Type of batteries

    Lead-acid, Lithium(2)

  • Charging curve

    3-phase (Bulk / Absorption / Float)

  • Maximum efficiency

    PV -> batterie : >94% / Batterie <–> AC : >93%

  • Battery charge

    Programmable (threshold / timing: multiple range by AC Grid)

  • Battery discharge

    Programmable ( 2 thresholds according to grid availability)

GENERAL

  • Dimensions (w x h x d)

    580 x 800 x 240 mm / 22.85 x 31.5 x 9.45 inch

  • Protection category

    IP 20 (indoor installation)

  • Weight

    46 kg

  • Technology

    TL (transformless)

  • Operating mode

    Smart grid / Back up – UPS / Off grid / On grid / VPP Ready

  • OS / Processor

    OS: Linux Debian 8.7 Jessie – CPU: ARM Cortex (Texas Instrument) 32 bits
    RAM : 8 GO of storage – Artificial Intelligence Inside – IOT Ready

  • I / O Connectors

    Wifi 802.11 b/g/n 2.4 GHz – 2 USB 2 – 1 Ethernet IP
    1 CAN bus – 2 RS485 – 1 relay 230 V 16A
    4 analog inputs : 1 temperature probe – 3 electrical measurements

  • Conditions of use

    Humidity level: 0 to 90% without condensation
    T°C : -20 to + 50°C, degressive power >40°C (15W/°C)

  • Compliance

    EN 62109-2 / EN 62109-1 / EN 62040-1 / DIN V VDE V 0126-1-1 (+VFR2013) / VDE-AR-N 4105 / EN 50438 DIN VDE V 0124-100 / Synergrid C10/11 / TF3.2.1 / AS4777.2 / AS4777.3 / NRS 097-2-1 / G83 / RD 1699

  • Guarantee

    10 years (3) / Extension to 20 years (optional)
